Packaging
Gross weight：1550.0 kg
CTN size：650.0cm*270.0cm*260.0cm
40 GP Container
Product Details
Advantage
Accurate temperature control, excellent heat distribution
The temperature control module developed by DTS has up to 12 stages of temperature control, and the step or linearity can be selected according to different product and process recipe heating modes, so that the repeatability and stability between batches of products are maximized well, the temperature can be controlled within ±0.3℃.
Rapid heating
No need to heat other media (such as hot water), the heating rate is very fast.
Perfect pressure control, suitable for a variety of packaging forms
The pressure control module developed by DTS continuously adjusts the pressure throughout the whole process to adapt the internal pressure changes of the product packaging, so that the degree of deformation of the product packaging is minimized, regardless of the rigid container of tin cans, aluminum cans or plastic bottles, plastic boxes or flexible containers can be easily satisfied, and the pressure can be controlled within ±0.05Bar.
Compliant with FDA/USDA certificate
DTS has experienced thermal verification experts and is a member of IFTPS in the United States. It fully cooperates with FDA-approved third-party thermal verification agencies. The experience of many North American customers has made DTS familiar with FDA/USDA regulatory requirements and cutting-edge sterilization technology.
Energy saving and environmental protection
The steam is directly heated, no exhaust is needed, and the minimum steam loss.
Low noise, create a quiet and comfortable working environment.
| Model |
Diameter(mm) |
Body Length (mm) |
Volume(m³) |
Length(mm) |
Width(mm) |
Height(mm) |
Basket size (L*W*Hmm) |
| DTS/12-3 |
1200 |
2400 |
3.1 |
4500 |
2350 |
2300 |
800*800*775 |
| DTS/12-4 |
1200 |
3600 |
4.5 |
5100 |
2350 |
2300 |
750*760*775 |
| DTS/12-5 |
1200 |
4500 |
5.5 |
6000 |
2350 |
2300 |
750*760*775 |
FAQ
Q: What methods of payment are acceptable?
A: FOB, CFR & CIF optional; It’s mainly depend on client’s requirement; Accepted payment types: T/T, L/C;
Q: What can you buy from us?
A: Water spray retort, immersion retort, steam retort, steam and air retort, rotary retort, lab retort, tunnel pasteurizing and cooling machine.
Q: Do you have any warranty about your equipment?
A: One year warranty. Frankly speaking, the quality of our machines is very stable. The machine will be tested many times before leaving the factory to ensure that when the machine arrives at your address, it is in the best condition. We also put in a set of spare parts that are prepared in advance from the machine's toolbox. During use, if you need any spare parts or have any questions, you can call us at any time.
Q: What's the lead time after placing order?
A: Usually it takes about 2-3 months after we received your deposit. However, it would depend on our production line schedule (the timing clients place order) and the complication of the item.
Q: What is the cost of shipping?
A: Shipping cost is based on the following elements:
1.Type of container needed
2. Number of packages
3. Gross weight
4. Package volume
5. Destination port
Q: What is the installation and training methods?
A: Our engineer will inspect and guide the installation of the equipment and the connection of the pipeline on site until theequipment is running smoothly.
