H23Q120Oriented electrical steel

Grain-oriented silicon steel is an alloy steel containing silicon. This type of steel is primarily used for manufacturing the cores of electrical devices such as transformers and motors due to its excellent magnetic properties. The characteristic of grain-oriented silicon steel is that it allows magnetic flux lines to flow in a specific direction, thereby reducing energy loss and enhancing the efficiency of the equipment.

NominalThickness(mm)0.20/ThicknessDeviation(mm)0.018/<0.020/ThicknessDeviation(mm)<0.030/LongitudinalThickness(mm)0~+2/Unevenness(%)<1.5/Camber 2m(mm)<1.0

NominalThickness(mm)0.23mm.Nominal1.10. CoreLoSSP1.7150(W/kg)1.10.Actual Core LossP.750(W/kg)1.08.MagneticInductionJ8oo(T)1.85.Min.LaminatioCoefficient(%)0.955.

Product Packaging:Simple packaging:

Export packaging:

Meet the requirements of marinetransportation to ensure the

quality of product transportation

and storage

1.inner and outer rust-proof

paper

2.VCl film (strengthen rust-proof)

3, inner and outer paper angle

guard

4.inner and outer protection

board (strengthen rust-proof)

5,inner and outer angle guard

6, bale belt (radial 4, axial 3)
