1. The entire box adopts a fully enclosed structure, with hot air circulating inside the box, which is energy-saving and efficient.

2. Adopting a built-in high-temperature resistant circulating fan, greatly reducing heat loss and strengthening heat transfer.

3. There is an adjustable air distribution plate inside the box, which can adjust the opening up and down to ensure uniform temperature inside the box.

4. The baking car baking tray is a unified industry standard, and the baking tray mesh tray is suitable for multiple industries with strong interchangeability.

5. Automatic constant temperature control, timed working hours, mechanized production, stable batch product quality.

6.The oven adopts a new type of heat pump air energy, which can save 30% energy consumption compared to traditional air.

Working principal:

01.  Put materials or materials into the chamber of the oven, then set the temperature and time of the oven, and the oven will automatically dry. The drying process of the oven first introduces fresh air from the outside into the oven, which is filtered through primary, medium, and high efficiency filters. The purified air is more beneficial for product quality assurance.

02.  Through a steam heat exchanger, the air is heated to a certain temperature, and then it is directly in contact with the material. During the air supply process, the wind deflector in the cabin will continuously adjust the direction, allowing the hot air to come into contact with the material more comprehensively and deliver it to all corners of the cabin to achieve balanced heating.

03.  The hot air comes into direct contact with the moist material, and the water vapor on the material will directly vaporize into water vapor, which will be dispersed into the indoor air. Then, the wet air is extracted from the inclined air duct under the baking tray, and a centrifugal fan is used to expel some of the wet air from the oven, while the other part of the air continues to circulate and heat, achieving the purpose of drying.

Drying effect:

Common drying equipment includes a drying oven, drying room, drying line, powder drum drying, and grain drying tower.

It can be divided into steam heating, microwave heating, infrared heating, hot air stove heating, etc.

Electric heating can also be divided into electric tube heating and air energy heating.

Air energy can also be divided into closed air energy and open closed integrated air energy.

Natural gas, coal, diesel, electricity, biomass particles, etc. can be used as heat sources.

Display of various drying equipment

01. Drying production line

02. Multi layer dryer

03. Air powered drying room

The main purpose of an oven is to dry materials and items in industries such as herbs, food, and light industry.

The drying oven is mainly used for agricultural product processing, fruit processing,  and seafood processing. For example, shiitake mushrooms, grapes, gardenia fruit, Zelan, orange peel, sweet potato, kelp, fish, sea cucumber, prune, ginger, rose fruit, banana, apple, etc. Drying is the process of manually controlling the evaporation of food moisture. There are also some foods that can have different flavors after drying. For example, mushrooms, Meigan cai.

Shipping & Packing

Standard export wooden case packing, fit for multiple handing and long distance marine shipping.

Delivery Time

For stock type, we can send within 48hrs after confirming order.

For customized type , delivery date need to be negotiated before taking order.
